1) Roam Marine Monitor Hub
The primary hub includes ambient temperature, humidity sensors along with sea state monitoring and a backup battery. All sensors connect to the bottom of the device and can be custom configured to meet your specific needs.
2) LTE-M Cellular Antenna
3) Secondary Battery or Pump Sensor x2
Wire these sensors into your second battery bank or bilge pumps for continual status. If you are connecting to your bilge pump we often recommend connecting to the manual bilge pump switch and the 6' wire is often more than enough. If you feel you will need more wire then order the 18' version for extended connection flexibility.
4) High Water Float Switch
Our high water float switch is custom built to provide a normally closed signal to our hub. Unlike many other float switch alarms this allows us to alarm if there is a problem with the wire to increase confidence in a high water event alarm. The float switch comes with a 15' wire.
5) Main Battery Supply Sensor
The main battery supply cable is 6' and is typically connected to your house batteries either at the battery or on a main bus bar in the electrical panel. The Roam Monitor both monitors battery voltage and uses this connection for it's primary power source.
6) GPS Antenna
Our GPS antenna comes with a 10' cable to allow for easy installation. The GPS antenna can be installed inside a fiberglass boat but should be kept away from metal and installed with the sticky side facing earth.
7) Mounting Brackets
Two mounting brackets and associated screws are included for quick mounting of the product.
Technical Specifications
| Operating Input Voltage | 5-32 VDC |
| Power Draw | 0.3W (0.030A @ 12V) |
| Internal Battery Capacity | 2600mAh |
| Battery Certification | UN 38.3 |
| Runtime on Internal Battery | 48 hours with GPS Enabled Up to 28 Days with GPS Disabled |
| Physical Dimensions | 5.0 in x 3.8 in x 1.5 in (127 mm x 97 mm x 38 mm) |
| Storage Temperature | -40ºF to 160ºF |
| Operating Temperature | -22ºF to 149ºF |
| Cellular | LTE CAT M1 Bands: B2, B4, B5, B12, B13, B25, B26, B66 |
| Local Wireless | 2.4Ghz |
| GPS Positioning | GNSS External Antenna |
| Certifications | FCC Part 15B PTCRB |
| Internal Sensors | Temperature Humidity Accelerometer (Sea State) |
| Audible Alarm | Piezo Internal to Hub |
| External Inputs | Input 1: Main Supply and Voltage Sense Input 2-4: Voltage/Pump/Float Switch |
